1/2" - 2" Class 150 ~ 1500 Forged Steel Cryogenic Gate Valve API 602, BS 5352

Model Number : Class 150~1500

Place of Origin : China

MOQ : 1 set

Packaging Details : Wooden box

Delivery Time : Within 15days

Payment Terms : T/T

Supply Ability : 1000pcs / month

Brand Name : OEM

Contact Now

1/2" - 2" Class 150 ~ 1500 Forged Steel Cryogenic Gate Valve API 602, BS 5352, ASME B16.34 , Connection End: ASME B2.1, ASME B16.11 Material: A105, LF2, F11, F22, F5, F304, F304L, F316, F316L

Cryogenic gate valve:
1)Standards:
A)Design&Manufacture: API 602, BS 5352, ASME B16.34
B)Face to Face: MSS SP-84
C)Connection End: ASME B2.1, ASME B16.11
D)Test and Inspection: API598
2)Sizes: 1/2" - 2" or DN12 - DN50
3)Pressure Rating: Class150 - Class1500 or PN16 - PN250
4)Material: A105, LF2, F11, F22, F5, F304, F304L, F316, F316L, etc.
5)Operated by: Handwheel

Standard Material Specifications:

NO.	Part Name	AS to ASTM		SS to ASTM
NO.	Part Name	Type LF2	Type LF3	Type F304(L)	Type F316(L)
1	Body	A350 LF2	A350 LF3	A182 F304(L)	A182 F316(L)
2	Seat Ring	A276 420	A276 410	A276 304(L)	A276 316(L)
3	Wedge	A350 LF2	A350 LF3	A182 F304(L)	A182 F316(L)
4	Gasket	Corrugated SS + graphite		SS + PTFE
5	Bonnet	A350 LF2	A350 LF3	A182 F304(L)	A182 F316(L)
6	Bonnet Bolt	A193 B7	A193 B7	A193 B8	A193 B8M
7	Stem	A182 F6	A182 F6	A182 F304(L)	A182 F316(L)
8	Stem Packing	Flexible Graphite		PTFE
9	Pin	A276 420		A276 304
10	Gland Eyebolt	A193 B7	A193 B16	A193 B8	A193 B8M
11	Gland	A276 410		A182 F304(L)	A182 F316(L)
12	Gland Flange	A105	A182 F11	A182 F304(L)	A182 F316(L)
13	Gland Nut	A194 2H	A194 4	A194 8	A194 8M
14	Yoke Nut	A276 420
15	Bearing Gasket	A473 431
16	Nameplate	SS
17	H. W. Lock Nut	A194 2H	A194 4	A194 8	A194 8M
18	Hand wheel	A197
Suitable Temperature		-40C	-101C	-196C

Dimensions(mm) And Weights(kg)

NPS (in)		3/8	1/2	3/4	1	1-1/4	1-1/2	2
L		79	92	111	120	120	140	178
H(OPEN)		330	333	360	407	475	475	551
W		100	100	125	160	160	180	200
Weights	Bolted	5.2	7.1	9.4	13.5	15.0	17.8	28.0
Weights	Welded	4.8	6.4	8.7	12.2	13.4	15.2	26.0

Product Tags:

power plant valves

gate globe valve

1/2" - 2" Class 150 ~ 1500 Forged Steel Cryogenic Gate Valve API 602, BS 5352 Images
